30mm 4 Positions Flat Head Tri-Color Ledlight Normally Open Stainless Steel Push Button Switch Manufacturers
Description
Basic Info
| Model NO. | RF |
| Protection | Waterproof |
| Feature | Flat |
| Wiring | Null Line and Live Line |
| Principle | Resistive |
| Application | Home Appliance, Electronics, Industrial, Apartment/Villa, Hotel |
| Type | Normal Open |
| Number of Switch | Single Control Switch |
| Structure | Power Built-in Type |
| Usage | Control Button, Start Button, Reset Button, Check Button, Control Switch |
| Kind | Single-pole on-off Switch |
| Contact Type | Type c Contact |
| Detection Method | Retro-reflective Mode |
| Brand | Rui Feng |
| Certification | ISO9001 |
| Customized | Acceptable |
| Operation Type | Momentary or Latching |
| Terminal | Solder Terminal,Screw Terminal |
| LED Voltage | 3V/6V/12V/24V/36V/120V/220V |
| IP Degree | IP65 |
| Item | Metal Push Button Switch |
| Front Head | Flat,High,Domed |
| The Body Material | Nickel-Plated Brass |
| LED Color | Red/Green/Yellow/White/Blue |
| Free Sample | Yes |
| Operating Temperature | -20 ~+55 |
| Function | on off |
| Mechanical Life | 300000 Times |
| Contact | Silver Plated or Silver Plated Gold |
| Transport Package | Carton Box |
| Specification | Dia. 16mm, 18mm, 20mm, 24mm, 28mm |
| Trademark | RF |
| Origin | Zhejiang, China (Mainland) |
| HS Code | 8536500000 |
| Production Capacity | 10000 Piece/Pieces Per Day |
Product Description
30mm 4 positions flat head tri-color ledlight normally open stainless steel push button switch manufacturers
Mounting hole dimension: Φ 30mmSwitch rating: 3A/250VACSwitch combination 1NO 1NC/2NO 2NCOperating type: Self-settable /Self-lockingHead shape: Facet /high facetShell material: Stainless Steel/Chrome Plated brassBead type: Single LED/ring LEDIP grade: IP40/IP67
| Product Name | Push Button Switch |
| Mounting Hole Diameter | 30mm |
| Operation Type | Momentary |
| Switch Combination | 1NO |
| Head Type | Domed head/ High head / Flat Head |
| Terminal type | 2 Pin Terminals/2 Screw Terminals |
| Enclosure Material | Brass nickel (Stainless steel available) |
| IP Degree | IP65,IK08 |
| Color | Red Yellow Green Blue White Black silver |
| Max. Current | 3A |
| Max. Voltage | 250V |
| Contact Resistance | 50 mΩ max |
| Insulation Resistance | 1000MΩ Min |
| Dielectric Intensity | 1500VAC |
| Operating Temperature | -20°C ~+55°C |
| Customized colored housing | Acceptable |
| Accessories | Nut, Rubber O-ring |
| Delivery Days | 1-7 days |
FAQ
1. How to buy your ideal products?
A: You can provide us your requirement, and we will recommend you.
2. How to pay?
A: TT and L/C are acceptable.30% TT as deposit, 70% before delivery..
3. What is the delivery time?
A: It depends on order quantity.Generally, the delivery time will be within 3 to 15 days.We have a lot of products in stock.
4. Package information
A:For inner box and master carton are made as per international standards,and we can make special designed for you if need.And if necessary,will be packed in pallet to avoid any damage.
B:Not more than 35kg per carton box,about 1000kg per pallet
5.How long to make a sample?Is it free?
A:3 days depending on the sample's complexity.Normally,our sample is free
6.How about the terms of delivery?
A.EXW; FOB;CFR;CIF;DDU..
6.How to contact us?
A:Send your inquiry details in the below,Click "send" now!
Service
1.Thousands of products in stock and ready to ship.
2.The most competitive pricing
3.Free shipment container loading
4.Putting the customer's needs first,always
5.On call,24 hours a day,7 days a week
